Description

The ArmorBuffa™ is a non-redirective, gating crash cushion designed to protect the ends of temporary concrete and steel barriers in work zones. It utilizes a steel nose and water-filled, high-performance plastic segments to absorb impact energy. The system is tested to MASH Test Level 3 standards and features a narrow profile, requiring no foundations or anchors. Its lightweight design allows for efficient assembly and relocation. The ArmorBuffa™ transitions seamlessly to various barrier profiles, including HighwayGuard and BG800 steel barriers. Manufactured from durable materials, the system’s components are recyclable, promoting sustainability.

Key Features

MASH Compliant: Tested to MASH Test Level 3 standards.

Space-Efficient Design: Narrow profile saves space on the worksite.

No Foundations Required: Eliminates the need for anchors or foundations.

Reusable Components: HDPE modules may be reusable after light impacts.

Easy Installation: Lightweight design facilitates efficient assembly and relocation.

Versatile Transitions: Compatible with various concrete and steel barrier profiles.

Recyclable Materials: Components are manufactured from recyclable materials.

Specifications

Effective Length: 30′ 7″ (9.3 m)

Width: 1′ 8″ (525 mm)

Height: 3′ 7″ (1.1 m)

Empty Weight: 950 lbs. (432 kg)

Ballasted Weight: 7,110 lbs. (3,225 kg)

Ballast Capacity: 740 gal. (2,800 L)
